ATA5745C-PXPW
RF RCVR UHF/ASK/FSK 433MHZ 24QFNManufacturer: Microchip Technology
Categories: RF Receivers
Quality Control: Learn More
The Microchip Technology ATA5745C-PXPW is a highly integrated UHF RF receiver designed for 433MHz operation. This component supports both ASK and FSK modulation schemes, offering a maximum data rate of 20kbps. It features exceptional receiver sensitivity of -113dBm, crucial for reliable communication in demanding environments. The ATA5745C-PXPW is packaged in a compact 24-VQFN (5x5) with an exposed pad, facilitating efficient PCB mounting and thermal management. Operating across a supply voltage range of 2.7V to 5.5V, it draws a receiving current of only 6.9mA. This device is commonly employed in Remote Keyless Entry (RKE) systems, telemetering applications, and various security technologies due to its robust performance and low power consumption. The antenna connection is designed for PCB surface mounting.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tube |
| Package / Case | 24-VQFN Exposed Pad |
| Sensitivity | -113dBm |
| Mounting Type | Surface Mount |
| Frequency | 433MHz |
| Memory Size | - |
| Modulation or Protocol | UHF, ASK, FSK |
| Data Interface | PCB, Surface Mount |
| Operating Temperature | -40°C ~ 105°C |
| Voltage - Supply | 2.7V ~ 3.3V, 4.5V ~ 5.5V |
| Applications | RKE, Telemetering, Security Technology |
| Current - Receiving | 6.9mA |
| Data Rate (Max) | 20kbps |
| Antenna Connector | PCB, Surface Mount |
| Supplier Device Package | 24-VQFN (5x5) |
