ATA3741P2-TGQY
RF RX ASK/FSK 300-450MHZ 20SOICManufacturer: Microchip Technology
Categories: RF Receivers
Quality Control: Learn More
The Microchip Technology ATA3741P2-TGQY is a highly sensitive RF receiver operating in the 300MHz to 450MHz frequency band. This component supports both ASK and FSK modulation schemes and achieves a data rate of up to 10kBaud. With a typical receiving current of 7mA and a sensitivity of -108dBm, the ATA3741P2-TGQY is optimized for low-power operation. It features a PCB, surface mount antenna connector and is supplied in a 20-SOIC package, measuring 7.50mm in width. This device is suitable for demanding applications in Remote Keyless Entry (RKE), Tire Pressure Monitoring (TPM), and security systems, requiring a supply voltage range of 4.5V to 5.5V and an operating temperature range of -40°C to 105°C. The part is provided on a Tape & Reel (TR) for efficient automated assembly.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tape & Reel (TR) |
| Package / Case | 20-SOIC (0.295"", 7.50mm Width) |
| Sensitivity | -108dBm |
| Mounting Type | Surface Mount |
| Frequency | 300MHz ~ 450MHz |
| Memory Size | - |
| Modulation or Protocol | ASK, FSK |
| Data Interface | PCB, Surface Mount |
| Operating Temperature | -40°C ~ 105°C |
| Voltage - Supply | 4.5V ~ 5.5V |
| Applications | RKE, TPM, Security Systems |
| Current - Receiving | 7mA |
| Data Rate (Max) | 10kBaud |
| Antenna Connector | PCB, Surface Mount |
| Supplier Device Package | 20-SOIC |
