MPP4204-206
SI PIN NON HERMETIC MMSMManufacturer: Microchip Technology
Categories: RF Diodes
Quality Control: Learn More
The Microchip Technology MPP4204-206 is a single PIN RF diode featuring a non-hermetic MMSM construction in a compact 0402 package. This component is rated for a maximum reverse voltage of 25V and exhibits a typical capacitance of 0.15pF at 10V and 1MHz. Its series resistance is 2 Ohms at 10mA and 100MHz, making it suitable for high-frequency switching applications. Operating within a temperature range of -55°C to 150°C, this diode is commonly utilized in wireless infrastructure, satellite communication systems, and radar applications where efficient RF signal control is critical. The MPP4204-206 is supplied in bulk packaging.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 40 week(s)Product Status: ActivePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 0402 (1005 Metric) |
| Diode Type | PIN - Single |
| Operating Temperature | -55°C ~ 150°C |
| Capacitance @ Vr, F | 0.15pF @ 10V, 1MHz |
| Resistance @ If, F | 2Ohm @ 10mA, 100MHz |
| Voltage - Peak Reverse (Max) | 25V |
| Supplier Device Package | 0402 |
