SST12LP15A-QVCE
IC AMP 802.11B/G/N 2.4GHZ 16VQFNManufacturer: Microchip Technology
Categories: RF Amplifiers
Quality Control: Learn More
Microchip Technology's SST12LP15A-QVCE is a high-performance RF power amplifier IC designed for 802.11b/g/n applications operating in the 2.4GHz to 2.485GHz spectrum. This device delivers a typical gain of 32dB and a P1dB of 29dBm, ensuring robust signal amplification for wireless communication systems. The SST12LP15A-QVCE is supplied in a compact 16-VQFN (3x3) package with an exposed pad, suitable for surface mount assembly. It operates from a supply voltage range of 3V to 4.2V and draws a quiescent current of 350mA. This component is widely utilized in wireless networking, consumer electronics, and IoT devices where reliable 2.4GHz band performance is critical. The SST12LP15A-QVCE is delivered in a Tape & Reel (TR) package for efficient automated manufacturing processes.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 16-VFQFN Exposed Pad |
| Mounting Type | Surface Mount |
| Frequency | 2.4GHz ~ 2.485GHz |
| RF Type | 802.11b/g/n |
| Voltage - Supply | 3V ~ 4.2V |
| Gain | 32dB |
| Current - Supply | 350mA |
| Noise Figure | - |
| P1dB | 29dBm |
| Test Frequency | 2.4GHz ~ 2.485GHz |
| Supplier Device Package | 16-VQFN (3x3) |
Request a Quote
