SST12CP11C-QUCE
IC AMP WIMAX 2.4-2.5GHZ 16UQFNManufacturer: Microchip Technology
Categories: RF Amplifiers
Quality Control: Learn More
Microchip Technology's SST12CP11C-QUCE is a high-performance RF amplifier designed for WiMax and WLAN applications operating within the 2.4GHz to 2.5GHz frequency range. This device offers a substantial 37dB of gain and a P1dB output power of 30dBm, ensuring robust signal amplification for demanding wireless communication systems. The SST12CP11C-QUCE is packaged in a compact 16-UQFN (3x3) surface mount configuration, facilitating efficient board space utilization. It operates from a 3.3V supply and draws a nominal current of 500mA, making it suitable for power-conscious designs. This component finds application in wireless infrastructure, consumer electronics, and networking equipment where reliable 2.4GHz band performance is critical.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 16-UFQFN Exposed Pad |
| Mounting Type | Surface Mount |
| Frequency | 2.4GHz ~ 2.5GHz |
| RF Type | WiMax, WLAN |
| Voltage - Supply | 3.3V |
| Gain | 37dB |
| Current - Supply | 500mA |
| Noise Figure | - |
| P1dB | 30dBm |
| Test Frequency | 2.4GHz |
| Supplier Device Package | 16-UQFN (3x3) |
Request a Quote
