DSC8104CI5-PROGRAMMABLE
MEMS OSC PROG XO HCSL 2.25-3.6VManufacturer: Microchip Technology
Categories: Programmable Oscillators
Quality Control: Learn More
Microchip Technology DSC8104CI5-PROGRAMMABLE is a highly configurable MEMS-based XO (Standard) oscillator with HCSL output. This device operates within a broad frequency range from 10 MHz to 460 MHz, offering precise programmability for custom frequency generation. Designed for demanding applications, it features a total frequency stability of ±10ppm and supports a standby function. The oscillator is housed in a compact 6-SMD, No Lead package, measuring 0.126" L x 0.098" W and a maximum seated height of 0.035". It is rated for an operating temperature range of -40°C to 85°C and supports supply voltages from 2.25V to 3.6V, with a maximum supply current of 42mA. This component is suitable for use in automotive and industrial sectors, conforming to AEC-Q100 standards.
Additional Information
Series: DSC8104RoHS Status: ROHS3 CompliantManufacturer Lead Time: 40 week(s)Product Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 6-SMD, No Lead |
| Size / Dimension | 0.126"" L x 0.098"" W (3.20mm x 2.50mm) |
| Mounting Type | Surface Mount |
| Output | HCSL |
| Function | Standby |
| Programmable Type | Programmed by Digi-Key (Enter your frequency in Web Order Notes) |
| Type | XO (Standard) |
| Operating Temperature | -40°C ~ 85°C |
| Frequency Stability | - |
| Voltage - Supply | 2.25V ~ 3.6V |
| Ratings | AEC-Q100 |
| Spread Spectrum Bandwidth | - |
| Current - Supply (Max) | 42mA |
| Height - Seated (Max) | 0.035"" (0.90mm) |
| Frequency Stability (Total) | ±10ppm |
| Available Frequency Range | 10 MHz ~ 460 MHz |
| Base Resonator | MEMS |
