DSC8004CI2-PROGRAMMABLE
MEMS OSC PROG XO CMOS 1.8V-3.3VManufacturer: Microchip Technology
Categories: Programmable Oscillators
Quality Control: Learn More
Microchip Technology's DSC8004CI2-PROGRAMMABLE is a programmable MEMS XO oscillator operating from 1.8V to 3.3V. This device offers a configurable output frequency range from 1 MHz to 150 MHz with CMOS output. Featuring a tight frequency stability of ±25ppm over an industrial temperature range of -40°C to 85°C, it includes a standby function. The oscillator is housed in a compact 4-SMD, No Lead package measuring 3.20mm x 2.50mm with a maximum seated height of 0.90mm, suitable for surface mounting. Typical applications include industrial automation, consumer electronics, and communications infrastructure. The part number DSC8004CI2-PROGRAMMABLE signifies a user-programmable frequency option.
Additional Information
Series: DSC8004RoHS Status: ROHS3 CompliantManufacturer Lead Time: 40 week(s)Product Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 4-SMD, No Lead |
| Size / Dimension | 0.126"" L x 0.098"" W (3.20mm x 2.50mm) |
| Mounting Type | Surface Mount |
| Output | CMOS |
| Function | Standby |
| Programmable Type | Programmed by Digi-Key (Enter your frequency in Web Order Notes) |
| Type | XO (Standard) |
| Operating Temperature | -40°C ~ 85°C |
| Frequency Stability | - |
| Voltage - Supply | 1.8V ~ 3.3V |
| Ratings | - |
| Spread Spectrum Bandwidth | - |
| Current - Supply (Max) | 16.6mA |
| Height - Seated (Max) | 0.035"" (0.90mm) |
| Frequency Stability (Total) | ±25ppm |
| Available Frequency Range | 1 MHz ~ 150 MHz |
| Base Resonator | MEMS |
