PDS-EM-8100-25G-US
ACCY POWER OVER ETHERNETManufacturer: Microchip Technology
Categories: Power over Ethernet (PoE)
Quality Control: Learn More
Microchip Technology's PDS-EM-8100-25G-US is a 3-port midspan Power over Ethernet injector designed for 10/100/1000 Mbps data rates. This device supports IEEE802.3at compliance, delivering up to 30W per port with a 535 mA output current at 56V. Its input voltage range is 100-240 VAC. The PDS-EM-8100-25G-US is suitable for applications requiring PoE connectivity in environments such as telecommunications, security systems, and wireless infrastructure. The unit measures 6.22" L x 5.28" W x 1.50" H and is FCC and VCCI approved, adhering to the 60950-1 standard. It operates within a temperature range of 0°C to 50°C and is supplied in bulk packaging.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Size / Dimension | 6.22"" L x 5.28"" W x 1.50"" H (158.0mm x 134.0mm x 38.0mm) |
| Voltage - Output | 56V |
| Mounting Type | Desktop |
| Voltage - Input | 100 ~ 240 VAC |
| Type | Midspan Injector |
| Operating Temperature | 0°C ~ 50°C |
| Data Rate | 10/100/1000 Mbps |
| Approval Agency | FCC, VCCI |
| Efficiency | - |
| Power (Watts) - Per Port | 30W |
| Compliance | IEEE802.3at |
| Current - Output | 535 mA |
| Number of Ports | 3 |
| Standard Number | 60950-1 |
