PD-AS-601/5
ACCY POWER OVER ETHERNETManufacturer: Microchip Technology
Categories: Power over Ethernet (PoE)
Quality Control: Learn More
Microchip Technology PD-AS-601-5 is a 5V Power over Ethernet (PoE) splitter designed for 10/100 Mbps data rates. This two-port device accepts a 48V input voltage, compliant with IEEE802.3af standards, and delivers a regulated 5V output at 2A per port, supporting up to 10W per port. Its desktop form factor, measuring 3.20" L x 2.20" W x 1.00" H (81.3mm x 55.9mm x 25.4mm), makes it suitable for various deployment scenarios. The PD-AS-601-5 is ideal for powering network devices in applications such as wireless access points, IP cameras, and VoIP phones where remote power delivery is required. It holds CE and FCC approvals.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Size / Dimension | 3.20"" L x 2.20"" W x 1.00"" H (81.3mm x 55.9mm x 25.4mm) |
| Voltage - Output | 5V |
| Mounting Type | Desktop |
| Voltage - Input | 48V |
| Type | Splitter |
| Operating Temperature | 0°C ~ 40°C |
| Data Rate | 10/100 Mbps |
| Approval Agency | CE, FCC |
| Efficiency | - |
| Power (Watts) - Per Port | 10W |
| Compliance | IEEE802.3af |
| Current - Output | 2 A |
| Number of Ports | 2 |
| Standard Number | - |
