PD69200C-016721-TR
MCUManufacturer: Microchip Technology
Categories: Power Over Ethernet (PoE) Controllers
Quality Control: Learn More
The Microchip Technology PD69200C-016721-TR is a 48-channel Power Sourcing Equipment (PSE) controller supporting IEEE 802.3af, 802.3at (PoE+), and 802.3bt standards. This surface mount device, packaged in a 32-QFN (5x5) with an exposed pad, operates within a voltage supply range of 3V to 3.63V and is rated for operation from -40°C to 85°C ambient temperature. It features auxiliary sense capabilities and is delivered in tape and reel packaging. This component is designed for high-density power delivery applications in networking infrastructure, industrial automation, and security systems requiring robust PoE capabilities.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 32-VFQFN Exposed Pad |
| Mounting Type | Surface Mount |
| Type | Controller (PSE) |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Voltage - Supply | 3V ~ 3.63V |
| Current - Supply | - |
| Internal Switch(s) | No |
| Standards | 802.3at (PoE+), 802.3af (PoE), 802.3bt |
| Supplier Device Package | 32-QFN (5x5) |
| Auxiliary Sense | Yes |
| Number of Channels | 48 |
| Power - Max | 90 W |
