MIC2566-0YTS
IC PWR SWITCH N-CHAN 1:1 14TSSOPManufacturer: Microchip Technology
Categories: Power Distribution Switches, Load Drivers
Quality Control: Learn More
The Microchip Technology MIC2566-0YTS is a dual N-channel power switch designed for efficient load management. This component, housed in a 14-TSSOP package, provides robust fault protection with fixed current limiting and over-temperature shutdown capabilities. Featuring a status flag for output monitoring, it operates with a 1:1 input-to-output ratio. The device is ideal for applications requiring precise control of 3.3V and 5V loads, such as in industrial automation, consumer electronics, and communication systems. Its surface mount design and 120mA output current capability make it suitable for compact board layouts. The typical ON-resistance is 1.4 Ohms.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDownload Free CAD Model:
Technical Details:
| Features | Status Flag |
| Packaging | Tube |
| Package / Case | 14-TSSOP (0.173"", 4.40mm Width) |
| Output Type | N-Channel |
| Mounting Type | Surface Mount |
| Number of Outputs | 2 |
| Interface | Logic |
| Switch Type | PCMCIA Switch |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Output Configuration | Low Side |
| Rds On (Typ) | 1.4Ohm |
| Input Type | Non-Inverting |
| Voltage - Load | 3.3V, 5V |
| Voltage - Supply (Vcc/Vdd) | Not Required |
| Current - Output (Max) | 120mA |
| Ratio - Input:Output | 1:1 |
| Supplier Device Package | 14-TSSOP |
| Fault Protection | Current Limiting (Fixed), Over Temperature |
