MIC2561-0BM TR
PCMCIA CARD SOCKET VCC AND VPP SManufacturer: Microchip Technology
Categories: Power Distribution Switches, Load Drivers
Quality Control: Learn More
Microchip Technology's MIC2561-0BM-TR is a PCMCIA switch featuring a 3:2 input to output ratio with two N-Channel MOSFET outputs, each capable of sourcing up to 200mA. This device integrates robust fault protection, including fixed current limiting and over-temperature shutdown, with a status flag output to indicate operational conditions. Designed for surface mounting on a 14-SOIC package, it operates from a 3.3V to 5V supply and supports load voltages of 3.3V, 5V, and 12V. The low-side output configuration and typical Rds(on) of 550mOhm make it suitable for power distribution applications. Industries leveraging this component include computing and industrial automation.
Additional Information
Series: -RoHS Status: Not applicableManufacturer Lead Time: No lead time information availableProduct Status: ActivePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | Status Flag |
| Packaging | Bulk |
| Package / Case | 14-SOIC (0.154"", 3.90mm Width) |
| Output Type | N-Channel |
| Mounting Type | Surface Mount |
| Number of Outputs | 2 |
| Interface | Logic |
| Switch Type | PCMCIA Switch |
| Operating Temperature | 0°C ~ 70°C (TA) |
| Output Configuration | Low Side |
| Rds On (Typ) | 550mOhm |
| Input Type | Non-Inverting |
| Voltage - Load | 3.3V, 5V, 12V |
| Voltage - Supply (Vcc/Vdd) | 3.3V ~ 5V |
| Current - Output (Max) | 200mA |
| Ratio - Input:Output | 3:2 |
| Supplier Device Package | 14-SOP |
| Fault Protection | Current Limiting (Fixed), Over Temperature |
