MIC2548A-2YM
IC PWR SWITCH N-CHAN 1:1 8SOICManufacturer: Microchip Technology
Categories: Power Distribution Switches, Load Drivers
Quality Control: Learn More
The Microchip Technology MIC2548A-2YM is a high-side N-channel power switch designed for robust power distribution. This device offers a 1.5A continuous output current capability and features adjustable current limiting and over-temperature fault protection for enhanced system reliability. The MIC2548A-2YM includes a status flag output, providing critical operational feedback. Its simplified ON/OFF interface and guaranteed 80mOhm on-resistance (Rds On) make it suitable for applications requiring efficient power management. Operating within a load voltage range of 2.7V to 5.5V, this component is commonly found in industrial automation, consumer electronics, and automotive systems. The device is supplied in an 8-SOIC surface-mount package.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 26 week(s)Product Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Features | Status Flag |
| Packaging | Tube |
| Package / Case | 8-SOIC (0.154"", 3.90mm Width) |
| Output Type | N-Channel |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Interface | ON/OFF |
| Switch Type | USB Switch |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Output Configuration | High Side |
| Rds On (Typ) | 80mOhm |
| Input Type | Non-Inverting |
| Voltage - Load | 2.7V ~ 5.5V |
| Voltage - Supply (Vcc/Vdd) | Not Required |
| Current - Output (Max) | 1.5A |
| Ratio - Input:Output | 1:1 |
| Supplier Device Package | 8-SOIC |
| Fault Protection | Current Limiting (Adjustable), Over Temperature |
