MIC2043-2BM-TR
IC PWR SWITCH N-CHAN 1:1 8SOICManufacturer: Microchip Technology
Categories: Power Distribution Switches, Load Drivers
Quality Control: Learn More
The Microchip Technology MIC2043-2BM-TR is an N-channel power switch designed for high-side load driving applications. This general-purpose switch offers a 1:1 input-to-output ratio and supports a load voltage range of 1.6V to 5.5V, with a maximum output current of 3A. Key fault protection features include adjustable current limiting, open load detection, over-temperature protection, and undervoltage lockout (UVLO). The device also incorporates slew rate control for reduced inrush current and a status flag for output condition monitoring. Its interface is managed via an ON/OFF pin. The MIC2043-2BM-TR is supplied in an 8-SOIC package on tape and reel, suitable for surface mounting. This component finds application in various industries including automotive, industrial, and consumer electronics where reliable power distribution is critical. The typical on-resistance (Rds On) is 40mOhm.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: DiscontinuedPackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | Slew Rate Controlled, Status Flag |
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-SOIC (0.154"", 3.90mm Width) |
| Output Type | N-Channel |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Interface | ON/OFF |
| Switch Type | General Purpose |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Output Configuration | High Side |
| Rds On (Typ) | 40mOhm |
| Input Type | Non-Inverting |
| Voltage - Load | 1.6V ~ 5.5V |
| Voltage - Supply (Vcc/Vdd) | 1.6V ~ 5.5V |
| Current - Output (Max) | 3A |
| Ratio - Input:Output | 1:1 |
| Supplier Device Package | 8-SOIC |
| Fault Protection | Current Limiting (Adjustable), Open Load Detect, Over Temperature, UVLO |
