MIC2043-1BM-TR

IC PWR SWITCH N-CHAN 1:1 8SOIC

Manufacturer: Microchip Technology

Categories: Power Distribution Switches, Load Drivers

Quality Control: Learn More

Microchip Technology's MIC2043-1BM-TR is a high-side N-channel power switch featuring a 1:1 input-to-output ratio and a maximum output current of 3A. This device integrates adjustable current limiting, open load detection, over-temperature protection, and undervoltage lockout (UVLO) for robust fault management. The 8-SOIC package facilitates surface mounting. Key features include slew rate control and a status flag for monitoring operational conditions. The MIC2043-1BM-TR operates across a voltage range of 1.6V to 5.5V for both supply and load, with a typical ON-resistance of 40mOhm. This component is utilized in applications such as industrial automation and consumer electronics.

Additional Information

Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: DiscontinuedPackaging: Tape & Reel (TR)Datasheet:
Technical Details:
FeaturesSlew Rate Controlled, Status Flag
PackagingTape & Reel (TR)
Package / Case8-SOIC (0.154"", 3.90mm Width)
Output TypeN-Channel
Mounting TypeSurface Mount
Number of Outputs1
InterfaceON/OFF
Switch TypeGeneral Purpose
Operating Temperature-40°C ~ 85°C (TA)
Output ConfigurationHigh Side
Rds On (Typ)40mOhm
Input TypeNon-Inverting
Voltage - Load1.6V ~ 5.5V
Voltage - Supply (Vcc/Vdd)1.6V ~ 5.5V
Current - Output (Max)3A
Ratio - Input:Output1:1
Supplier Device Package8-SOIC
Fault ProtectionCurrent Limiting (Adjustable), Open Load Detect, Over Temperature, UVLO
