MIC2026-2BN
DUAL-CH PWR DISTRIBUTION SWITCHManufacturer: Microchip Technology
Categories: Power Distribution Switches, Load Drivers
Quality Control: Learn More
Power Switch/Driver 1:2 N-Channel 1.25A 8-PDIP
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | Slew Rate Controlled, Status Flag |
| Packaging | Bulk |
| Package / Case | 8-DIP (0.300"", 7.62mm) |
| Output Type | N-Channel |
| Mounting Type | Through Hole |
| Number of Outputs | 2 |
| Interface | ON/OFF |
| Switch Type | General Purpose |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Output Configuration | High Side |
| Rds On (Typ) | 90mOhm |
| Input Type | Inverting |
| Voltage - Load | 2.7V ~ 5.5V |
| Voltage - Supply (Vcc/Vdd) | Not Required |
| Current - Output (Max) | 1.25A |
| Ratio - Input:Output | 1:2 |
| Supplier Device Package | 8-PDIP |
| Fault Protection | Current Limiting (Fixed), Over Temperature, UVLO |
Request a Quote
