MIC2026-1BM
IC PWR SWITCH N-CHAN 1:2 8SOICManufacturer: Microchip Technology
Categories: Power Distribution Switches, Load Drivers
Quality Control: Learn More
Microchip Technology's MIC2026-1BM is a general-purpose N-channel power switch, featuring a 1:2 output configuration. This surface-mount device, housed in an 8-SOIC package, delivers a maximum output current of 1.25A. Integrated fault protection includes fixed current limiting, over-temperature protection, and undervoltage lockout (UVLO). Key features include slew rate control and a status flag for monitoring. Designed for high-side switching, its typical Rds On is 90mOhm. The operating temperature range is -40°C to 85°C. This component finds application in various industrial and consumer electronics, including power distribution and control systems.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: DiscontinuedPackaging: TubeDownload Free CAD Model:
Technical Details:
| Features | Slew Rate Controlled, Status Flag |
| Packaging | Tube |
| Package / Case | 8-SOIC (0.154"", 3.90mm Width) |
| Output Type | N-Channel |
| Mounting Type | Surface Mount |
| Number of Outputs | 2 |
| Interface | ON/OFF |
| Switch Type | General Purpose |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Output Configuration | High Side |
| Rds On (Typ) | 90mOhm |
| Input Type | Non-Inverting |
| Voltage - Load | 2.7V ~ 5.5V |
| Voltage - Supply (Vcc/Vdd) | Not Required |
| Current - Output (Max) | 1.25A |
| Ratio - Input:Output | 1:2 |
| Supplier Device Package | 8-SOIC |
| Fault Protection | Current Limiting (Fixed), Over Temperature, UVLO |
