DRF1201
IC PWR DRIVER N-CHANNEL 1:1Manufacturer: Microchip Technology
Categories: Power Distribution Switches, Load Drivers
Quality Control: Learn More
Power Switch/Driver 1:1 N-Channel 26A
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 30 week(s)Product Status: ActivePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Package / Case | 10-SMD Module |
| Output Type | N-Channel |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Interface | ON/OFF |
| Switch Type | General Purpose |
| Operating Temperature | - |
| Output Configuration | Low Side |
| Rds On (Typ) | 550mOhm |
| Input Type | Inverting, Non-Inverting |
| Voltage - Load | 10V ~ 15V |
| Voltage - Supply (Vcc/Vdd) | - |
| Current - Output (Max) | 26A |
| Ratio - Input:Output | 1:1 |
| Supplier Device Package | - |
| Fault Protection | - |
Request a Quote
