ATA6830-PKH
IC MTR DRVR BIPOLAR 7-20V 28QFNManufacturer: Microchip Technology
Categories: Motor Drivers, Controllers
Quality Control: Learn More
The Microchip Technology ATA6830-PKH is a fully integrated bipolar motor driver featuring a serial interface and NMOS/PMOS technology. This automotive-grade component provides control and power stages for bipolar steppers, delivering up to 1.1A output current. It operates within a 7V to 20V voltage range for both supply and load. The device is housed in a 28-QFN (7x7) exposed pad package, suitable for surface mounting. Its output configuration includes four half bridges, facilitating precise motor control. The ATA6830-PKH is designed for demanding applications within the automotive sector, operating reliably across a wide temperature range of -40°C to 150°C.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 28-VQFN Exposed Pad |
| Mounting Type | Surface Mount |
| Function | Driver - Fully Integrated, Control and Power Stage |
| Current - Output | 1.1A |
| Interface | Serial |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Output Configuration | Half Bridge (4) |
| Voltage - Supply | 7V ~ 20V |
| Applications | - |
| Technology | NMOS, PMOS |
| Voltage - Load | 7V ~ 20V |
| Supplier Device Package | 28-QFN (7x7) |
| Motor Type - Stepper | Bipolar |
| Motor Type - AC, DC | - |
| Step Resolution | - |
| Grade | Automotive |
