AT91SAM9XE512-QU
IC MPU SAM9XE 180MHZ 208QFPManufacturer: Microchip Technology
Categories: Microprocessors
Quality Control: Learn More
Microchip Technology's AT91SAM9XE512-QU is a 32-bit ARM926EJ-S microprocessor featuring a single core operating at 180MHz. This SAM9XE series component is housed in a 208-PQFP (28x28) package, suitable for surface mount applications. It supports multiple interfaces including EBI/EMI, I2C, ISI, MMC/SD/SDIO, SPI, SSC, and UART/USART. The device integrates three USB 2.0 ports and a 10/100Mbps Ethernet controller. RAM controller support extends to SDRAM and SRAM. Display functionalities are addressed through integrated LCD and touchscreen controllers. The component operates within a temperature range of -40°C to 85°C and offers configurable I/O voltage levels of 1.8V, 2.5V, and 3.3V. This microprocessor is commonly utilized in industrial automation, consumer electronics, and networking applications.
Additional Information
Series: SAM9XERoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDownload Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 208-BFQFP |
| Mounting Type | Surface Mount |
| Speed | 180MHz |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Core Processor | ARM926EJ-S |
| Voltage - I/O | 1.8V, 2.5V, 3.3V |
| Supplier Device Package | 208-PQFP (28x28) |
| Ethernet | 10/100Mbps |
| USB | USB 2.0 (3) |
| Number of Cores/Bus Width | 1 Core, 32-Bit |
| Co-Processors/DSP | - |
| RAM Controllers | SDRAM, SRAM |
| Graphics Acceleration | No |
| Display & Interface Controllers | LCD, Touchscreen |
| Security Features | - |
| SATA | - |
| Additional Interfaces | EBI/EMI, I2C, ISI, MMC/SD/SDIO, SPI, SSC, UART/USART |
