PIC18F25Q43T-I/SS
IC MCU 8BIT 32KB FLASH 28SSOPManufacturer: Microchip Technology
Categories: Microcontrollers
Quality Control: Learn More
Microchip Technology PIC® XLP™ 18F microcontroller, part number PIC18F25Q43T-I-SS, is an 8-bit MCU featuring a 64MHz core processor. This device offers 32KB of FLASH program memory and 2KB of RAM, complemented by 1KB of EEPROM. The PIC18F25Q43T-I-SS integrates multiple communication interfaces including I2C, LINbus, SPI, and UART/USART, along with a 24-channel 12-bit Analog-to-Digital converter and an 8-bit Digital-to-Analog converter. On-chip peripherals include Brown-out Detect/Reset, LVD, POR, PWM, and WDT. Supplied in a 28-SSOP surface-mount package, it operates from 1.8V to 5.5V within an ambient temperature range of -40°C to 85°C. This component is suitable for applications in automotive, industrial, and consumer electronics.
Additional Information
Series: PIC® XLP™ 18FRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: DiscontinuedPackaging: Cut Tape (CT)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Cut Tape (CT) |
| Package / Case | 28-SSOP (0.209"", 5.30mm Width) |
| Mounting Type | Surface Mount |
| Speed | 64MHz |
| Program Memory Size | 32KB (32K x 8) |
| RAM Size | 2K x 8 |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | FLASH |
| EEPROM Size | 1K x 8 |
| Core Processor | PIC |
| Data Converters | A/D 24x12b; D/A 1x8b |
| Core Size | 8-Bit |
| Voltage - Supply (Vcc/Vdd) | 1.8V ~ 5.5V |
| Connectivity | I2C, LINbus, SPI, UART/USART |
| Peripherals | Brown-out Detect/Reset, LVD, POR, PWM, WDT |
| Supplier Device Package | 28-SSOP |
| Number of I/O | 25 |
| Programmable | Not Verified |
