ATXMEGA256A3B-AU

IC MCU 8/16BIT 256KB FLSH 64TQFP

Manufacturer: Microchip Technology

Categories: Microcontrollers

Quality Control: Learn More

Microchip Technology AVR® XMEGA® A3B microcontroller, part number ATXMEGA256A3B-AU. This 8/16-bit AVR MCU operates at 32MHz, featuring 256KB of FLASH program memory and 16KB of SRAM. The device includes a 4KB EEPROM and offers extensive connectivity options including I2C, IrDA, SPI, and UART/USART. Peripheral capabilities encompass DMA, multiple PWM modules, Brown-out Detect/Reset, POR, and WDT. Data conversion is supported by 16x 12-bit ADCs and 2x 12-bit DACs. Packaged in a 64-TQFP (14x14) surface-mount format, this component is suitable for applications requiring robust control and high-speed data processing. Typical industries utilizing this microcontroller include industrial automation, medical devices, and consumer electronics.

Additional Information

Series: AVR® XMEGA® A3BRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tray
Technical Details:
PackagingTray
Package / Case64-TQFP
Mounting TypeSurface Mount
Speed32MHz
Program Memory Size256KB (128K x 16)
RAM Size16K x 8
Operating Temperature-40°C ~ 85°C (TA)
Oscillator TypeInternal
Program Memory TypeFLASH
EEPROM Size4K x 8
Core ProcessorAVR
Data ConvertersA/D 16x12b; D/A 2x12b
Core Size8/16-Bit
Voltage - Supply (Vcc/Vdd)1.6V ~ 3.6V
ConnectivityI2C, IrDA, SPI, UART/USART
PeripheralsBrown-out Detect/Reset, DMA, POR, PWM, WDT
Supplier Device Package64-TQFP (14x14)
Number of I/O49
ProgrammableNot Verified
