AT89C51CC01UA-RLTUM
IC MCU 8BIT 32KB FLASH 44VQFPManufacturer: Microchip Technology
Categories: Microcontrollers
Quality Control: Learn More
Microchip Technology AT89C CAN series microcontroller, part number AT89C51CC01UA-RLTUM. This 8-bit 80C51 core microcontroller operates at 40MHz and features 32KB of FLASH program memory. It includes 1.25KB of RAM and 2KB of EEPROM. Connectivity options include CANbus and UART/USART. The device is equipped with 8x10-bit A/D converters and peripherals such as POR, PWM, and WDT. With 34 programmable I/O pins, this surface mount component is housed in a 44-VQFP (10x10) package. The operating temperature range is -40°C to 85°C. This microcontroller is suitable for applications in the automotive and industrial sectors. The component is supplied in a tray.
Additional Information
Series: AT89C CANRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 44-LQFP |
| Mounting Type | Surface Mount |
| Speed | 40MHz |
| Program Memory Size | 32KB (32K x 8) |
| RAM Size | 1.25K x 8 |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Oscillator Type | External |
| Program Memory Type | FLASH |
| EEPROM Size | 2K x 8 |
| Core Processor | 80C51 |
| Data Converters | A/D 8x10b |
| Core Size | 8-Bit |
| Voltage - Supply (Vcc/Vdd) | 3V ~ 5.5V |
| Connectivity | CANbus, UART/USART |
| Peripherals | POR, PWM, WDT |
| Supplier Device Package | 44-VQFP (10x10) |
| Number of I/O | 34 |
| Programmable | Verified |
