PIC18LF65K80T-I/PT
RISC Microcontroller, 8-Bit, FLASH, PIC18 CPU, 64MHz, CMOS, PQFP64Manufacturer: Microchip Technology
Categories: Microcontrollers
Quality Control: Learn More
Microchip Technology PIC18LF65K80 family 8-bit RISC microcontroller featuring a 64MHz PIC18 CPU. This device offers 32KB of FLASH program memory and 3.6KB of data RAM, complemented by 1024 bytes of Data EEPROM. It incorporates a suite of peripherals including 5 timers, 2 analog comparators, 2 PWM channels, and 2 EUSART modules. Connectivity options extend to ECAN and MSSP. The microcontroller supports low-power operation and includes an 11-channel 12-bit ADC. Designed for surface mounting, it is housed in a 64-pin TQFP package with a 0.5mm terminal pitch. Applications span automotive, industrial control, and consumer electronics. This component operates within an extended temperature range of -40°C to +85°C.
Additional Information
Series: PIC18LF65K80RoHS Status: RoHS CompliantManufacturer Lead Time: 5Product Status: ActivePackaging: TRDatasheet:Download Free CAD Model:
Technical Details:
| Format | Fixed Point |
| Width | 10.0000 |
| Technology | CMOS |
| Connectivity | ECAN, EUSART(2), MSSP, PSP |
| Peripherals | ANALOG COMPARATOR(2), BOR, CTMU, POR, PWM(5), TIMER(5), WDT |
| Speed | 64.00000000 |
| Length | 10.0000 |
| A_D_Converters | 11-Ch 12-Bit |
| ADC_Channels | Yes |
| Address_Bus_Width | 0 |
| Bit_Size | 8 |
| Boundary_Scan | No |
| Clock_Frequency_Max | 64.0000000000000000 |
| CPU_Family | PIC18 |
| DAC_Channels | No |
| Data_EEPROM_Size | 1024 |
| Data_RAM_Size | 3648 |
| DMA_Channels | No |
| External_Data_Bus_Width | 0 |
| Integrated_Cache | No |
| JESD_30_Code | S-PQFP-G64 |
| Low_Power_Mode | Yes |
| Number_of_External_Interrupts | 4 |
| Number_of_I_O_Lines | 54 |
| Number_of_Serial_I_Os | 2 |
| Number_of_Terminals | 64 |
| Number_of_Timers | 5 |
| On_Chip_Data_RAM_Width | 8 |
| Operating_Temperature_Max | 85.0000 |
| Operating_Temperature_Min | -40.0000 |
| Package_Body_Material | PLASTIC/EPOXY |
| Package_Code | TFQFP |
| Package_Equivalence_Code | TQFP64,.47SQ |
| Package_Shape | Square |
| Package_Style | FLATPACK, THIN PROFILE, FINE PITCH |
| Program_Memory_Size | 32768 |
| Program_Memory_Type | FLASH |
| Program_Memory_Width | 8 |
| PWM_Channels | Yes |
| Screening_Level_Reference_Standard | TS 16949 |
| Seated_Height_Max | 1.2000 |
| Supply_Current_Max | 5.00000000 |
| Supply_Voltage_Max | 3.6000 |
| Supply_Voltage_Min | 1.8000 |
| Supply_Voltage_Nom | 3.3000 |
| Surface_Mount | Yes |
| Terminal_Form | Gull Wing |
| Terminal_Pitch | 0.500 |
| Terminal_Position | QUAD |
| uPs_uCs_Peripheral_ICs_Type | MICROCONTROLLER, RISC |
