SST39VF1601C-70-4I-MAQE
IC FLASH 16MBIT PARALLEL 48WFBGAManufacturer: Microchip Technology
Categories: Memory
Quality Control: Learn More
Microchip Technology's SST39VF1601C-70-4I-MAQE is a 16Mbit parallel FLASH memory device from the SST39 MPF™ series. This non-volatile memory offers a 70 ns access time and a memory organization of 1M x 16. Designed for surface mount applications, it utilizes a 48-WFBGA (6x4) package and operates over an industrial temperature range of -40°C to 85°C. The device supports a supply voltage range of 2.7V to 3.6V, with a word/page write cycle time of 10µs. This component is suitable for applications in the automotive, industrial, and communications sectors.
Additional Information
Series: SST39 MPF™RoHS Status: ROHS3 CompliantManufacturer Lead Time: 8 week(s)Product Status: ActivePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 48-WFBGA |
| Mounting Type | Surface Mount |
| Memory Size | 16Mbit |
| Memory Type | Non-Volatile |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Voltage - Supply | 2.7V ~ 3.6V |
| Technology | FLASH |
| Memory Format | FLASH |
| Supplier Device Package | 48-WFBGA (6x4) |
| Write Cycle Time - Word, Page | 10µs |
| Memory Interface | Parallel |
| Access Time | 70 ns |
| Memory Organization | 1M x 16 |
| Programmable | Not Verified |
