TS8882VF20
Math Coprocessor, 32-Bit, CMOS, CQFP68Manufacturer: Microchip Technology
Categories: Math Processors
Quality Control: Learn More
Microchip Technology presents the TS8882VF20, a 32-bit CMOS math coprocessor from the TS8882 series. This component features a 68-terminal CQFP (Ceramic Quad Flat Pack) package with a 1.27mm terminal pitch, designed for surface mounting. Operating within a supply voltage range of 4.5V to 5.5V, with a nominal 5.0V, it offers a maximum clock frequency of 20.000 MHz. The TS8882VF20 supports an external data bus width of 32 bits and an address bus width of 4 bits. Its operating temperature spans from -40°C to +85°C. This device is suitable for applications in industrial automation, telecommunications, and high-performance computing. The package body material is ceramic with a metal-sealed cofired construction, adhering to the S-CQFP-G68 JESD-30 code.
Additional Information
Series: TS8882RoHS Status: Manufacturer Lead Time: Product Status: Active-UnconfirmedPackaging: Datasheet:Download Free CAD Model:
Technical Details:
| Technology | CMOS |
| Address_Bus_Width | 4 |
| Boundary_Scan | No |
| Clock_Frequency_Max | 20.0000000000000000 |
| External_Data_Bus_Width | 32 |
| JESD_30_Code | S-CQFP-G68 |
| Number_of_Terminals | 68 |
| Operating_Temperature_Max | 85.0000 |
| Operating_Temperature_Min | -40.0000 |
| Package_Body_Material | CERAMIC, METAL-SEALED COFIRED |
| Package_Code | QFP |
| Package_Equivalence_Code | QFP68,1.1SQ,50 |
| Package_Shape | Square |
| Package_Style | FlatPack |
| Supply_Current_Max | 136.00000000 |
| Supply_Voltage_Max | 5.5000 |
| Supply_Voltage_Min | 4.5000 |
| Supply_Voltage_Nom | 5.0000 |
| Surface_Mount | Yes |
| Terminal_Form | Gull Wing |
| Terminal_Pitch | 1.270 |
| Terminal_Position | QUAD |
| uPs_uCs_Peripheral_ICs_Type | MATH PROCESSOR, COPROCESSOR |
