TC1303A-ZP0EUNTR
IC REG DL BUCK/LNR SYNC 10MSOPManufacturer: Microchip Technology
Categories: Linear + Switching
Quality Control: Learn More
Microchip Technology's TC1303A-ZP0EUNTR is a dual-output power management IC featuring a 2MHz synchronous buck regulator and a linear low-dropout (LDO) regulator. This device is designed for applications requiring efficient voltage regulation, including automotive infotainment systems and industrial control equipment. The synchronous buck output provides 500mA with adjustable voltage, while the LDO output delivers a fixed 1.8V at 300mA. The TC1303A-ZP0EUNTR operates from a 2.7V to 5.5V supply and includes sequencing capabilities. Packaged in a 10-MSOP on tape and reel, this component is suitable for surface mount assembly and operates across a temperature range of -40°C to 85°C.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 11 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 10-TFSOP, 10-MSOP (0.118"", 3.00mm Width) |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 2.7V ~ 5.5V |
| Frequency - Switching | 2MHz |
| Topology | Step-Down (Buck) Synchronous (1), Linear (LDO) (1) |
| Supplier Device Package | 10-MSOP |
| Voltage/Current - Output 1 | Adj, 500mA |
| Voltage/Current - Output 2 | 1.8V, 300mA |
| Voltage/Current - Output 3 | - |
| w/LED Driver | No |
| w/Supervisor | No |
| w/Sequencer | Yes |
| Number of Outputs | 2 |
