TC1303A-ZA0EMFTR
IC REG DL BUCK/LINEAR SYNC 10DFNManufacturer: Microchip Technology
Categories: Linear + Switching
Quality Control: Learn More
Microchip Technology TC1303A-ZA0EMFTR is a dual-output power management IC featuring one synchronous step-down (buck) regulator and one linear (LDO) regulator. This device operates with a switching frequency of 2MHz and is housed in a 10-DFN (3x3) surface-mount package. The buck output is adjustable and capable of delivering up to 500mA, while the fixed linear output provides 3.3V at 300mA. The TC1303A-ZA0EMFTR supports input voltages from 2.7V to 5.5V and includes a power-on sequencing capability. It is designed for applications in consumer electronics and industrial systems requiring efficient and flexible voltage regulation. The component is supplied on a tape and reel for automated assembly and operates within an ambient temperature range of -40°C to 85°C.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 8 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 10-VFDFN Exposed Pad |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 2.7V ~ 5.5V |
| Frequency - Switching | 2MHz |
| Topology | Step-Down (Buck) Synchronous (1), Linear (LDO) (1) |
| Supplier Device Package | 10-DFN (3x3) |
| Voltage/Current - Output 1 | Adj, 500mA |
| Voltage/Current - Output 2 | 3.3V, 300mA |
| Voltage/Current - Output 3 | - |
| w/LED Driver | No |
| w/Supervisor | No |
| w/Sequencer | Yes |
| Number of Outputs | 2 |
