MIC5514-3.3YMT-T5
IC REG LINEAR 3.3V 300MA 6TDFNManufacturer: Microchip Technology
Categories: Linear, Low Drop Out (LDO) Regulators
Quality Control: Learn More
Microchip Technology's MIC5514-3-3YMT-T5 is a fixed 3.3V positive linear voltage regulator designed for efficient power management. This device delivers a stable 300mA output current with a low dropout voltage of 0.38V at full load, ensuring optimal performance even under demanding conditions. It features an enable pin for precise control and boasts a low quiescent current of 55 µA, minimizing power consumption in battery-powered applications. The regulator operates from an input voltage range of up to 5.5V and offers excellent power supply rejection ratio (PSRR) of 65dB at 1kHz. Housed in a compact 6-TDFN (1.6x1.6) package, this component is ideal for surface mount integration in portable electronics, industrial control systems, and automotive applications. The MIC5514-3-3YMT-T5 is supplied on tape and reel.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: DiscontinuedPackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 6-UFDFN Exposed Pad |
| Output Type | Fixed |
| Mounting Type | Surface Mount |
| Current - Output | 300mA |
| Operating Temperature | -40°C ~ 125°C |
| Output Configuration | Positive |
| Current - Quiescent (Iq) | 55 µA |
| Voltage - Input (Max) | 5.5V |
| Number of Regulators | 1 |
| Supplier Device Package | 6-TDFN (1.6x1.6) |
| Voltage - Output (Max) | - |
| Voltage - Output (Min/Fixed) | 3.3V |
| Control Features | Enable |
| PSRR | 65dB (1kHz) |
| Voltage Dropout (Max) | 0.38V @ 300mA |
| Protection Features | - |
| Current - Supply (Max) | 65 µA |
