MIC5253-2.85BC5 TR
IC REG LINEAR 2.85V 100MA SC70-5Manufacturer: Microchip Technology
Categories: Linear, Low Drop Out (LDO) Regulators
Quality Control: Learn More
The Microchip Technology Teeny™ series MIC5253-2-85BC5-TR is a fixed 2.85V positive linear voltage regulator. This device delivers a stable 100mA output current with a low dropout voltage of 0.3V at 100mA. Featuring an enable pin for power control, it offers protection against over current, over temperature, and under voltage lockout (UVLO). The quiescent current is rated at 100µA, with a supply current not exceeding 150µA. This component is housed in a compact SC-70-5 (SOT-353) package, supplied on tape and reel, and operates across an industrial temperature range of -40°C to 125°C. Its high power supply rejection ratio (PSRR) of 70dB to 65dB from 1kHz to 10kHz makes it suitable for applications requiring efficient noise filtering, such as portable electronics, battery-powered devices, and automotive systems.
Additional Information
Series: Teeny™RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 5-TSSOP, SC-70-5, SOT-353 |
| Output Type | Fixed |
| Mounting Type | Surface Mount |
| Current - Output | 100mA |
| Operating Temperature | -40°C ~ 125°C |
| Output Configuration | Positive |
| Current - Quiescent (Iq) | 100 µA |
| Voltage - Input (Max) | 5.5V |
| Number of Regulators | 1 |
| Supplier Device Package | SC-70-5 |
| Voltage - Output (Max) | - |
| Voltage - Output (Min/Fixed) | 2.85V |
| Control Features | Enable |
| PSRR | 70dB ~ 65dB (1kHz ~ 10kHz) |
| Voltage Dropout (Max) | 0.3V @ 100mA |
| Protection Features | Over Current, Over Temperature, Under Voltage Lockout (UVLO) |
| Current - Supply (Max) | 150 µA |
