MIC5247-1.55BM5-TR
IC REG LIN 1.55V 150MA SOT23-5Manufacturer: Microchip Technology
Categories: Linear, Low Drop Out (LDO) Regulators
Quality Control: Learn More
Microchip Technology MIC5247-1-55BM5-TR is a fixed, positive linear voltage regulator IC designed for applications requiring stable 1.55V output with a 150mA current capability. This device features a low dropout voltage of 0.15V at 150mA and a low quiescent current of 150µA. The regulator includes an enable pin for power control and robust protection features such as over-current, over-temperature, and under-voltage lockout (UVLO). Its high power supply rejection ratio (PSRR) of 50dB at 1kHz makes it suitable for noise-sensitive applications. Packaged in a compact SOT-23-5 (SC-74A, SOT-753) surface-mount configuration and supplied on tape and reel, this component is widely utilized in various industrial and consumer electronics, including battery-powered devices and portable equipment. The maximum input voltage for this regulator is 6V.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: DiscontinuedPackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | SC-74A, SOT-753 |
| Output Type | Fixed |
| Mounting Type | Surface Mount |
| Current - Output | 150mA |
| Operating Temperature | -40°C ~ 125°C |
| Output Configuration | Positive |
| Current - Quiescent (Iq) | 150 µA |
| Voltage - Input (Max) | 6V |
| Number of Regulators | 1 |
| Supplier Device Package | SOT-23-5 |
| Voltage - Output (Max) | - |
| Voltage - Output (Min/Fixed) | 1.55V |
| Control Features | Enable |
| PSRR | 50dB (1kHz) |
| Voltage Dropout (Max) | 0.15V @ 150mA |
| Protection Features | Over Current, Over Temperature, Under Voltage Lockout (UVLO) |
