MIC29312BU TR
IC REG LINEAR POS ADJ 3A TO263-5Manufacturer: Microchip Technology
Categories: Linear, Low Drop Out (LDO) Regulators
Quality Control: Learn More
The Microchip Technology MIC29312BU-TR is a high-performance, low-dropout linear voltage regulator IC. This adjustable positive output regulator is capable of delivering up to 3A of current with a low dropout voltage of 1V at 3A. It features an input voltage range up to 16V and an adjustable output voltage from 1.24V to 15V. The device includes an enable pin for control and offers robust protection features including over current, over temperature, and reverse polarity protection. Designed for surface mounting, the MIC29312BU-TR is supplied in a TO-263-5 package on tape and reel. This component is utilized in applications such as automotive, industrial control, and power supply systems where efficient and stable voltage regulation is required.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | TO-263-6, D2PAK (5 Leads + Tab), TO-263BA |
| Output Type | Adjustable |
| Mounting Type | Surface Mount |
| Current - Output | 3A |
| Operating Temperature | 0°C ~ 125°C |
| Output Configuration | Positive |
| Current - Quiescent (Iq) | 20 mA |
| Voltage - Input (Max) | 16V |
| Number of Regulators | 1 |
| Supplier Device Package | TO-263-5 |
| Voltage - Output (Max) | 15V |
| Voltage - Output (Min/Fixed) | 1.24V |
| Control Features | Enable |
| PSRR | - |
| Voltage Dropout (Max) | 1V @ 3A |
| Protection Features | Over Current, Over Temperature, Reverse Polarity |
| Current - Supply (Max) | 150 mA |
