MIC29201-4.8BT
IC REG LIN 4.85V 400MA TO220-5Manufacturer: Microchip Technology
Categories: Linear, Low Drop Out (LDO) Regulators
Quality Control: Learn More
Microchip Technology MIC29201-4-8BT is a low-dropout linear voltage regulator. This positive fixed output device provides 4.85V with a maximum output current of 400mA. The quiescent current is rated at 300 µA, with a maximum supply current of 12 mA. It features an enable pin for control and offers protection against load dump, over current, and reverse polarity. The input voltage range extends up to 26V, and the dropout voltage is a maximum of 0.75V at the full 400mA load. Packaged in a TO-220-5 through-hole configuration, this regulator is suitable for applications in automotive and industrial sectors.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | TO-220-5 |
| Output Type | Fixed |
| Mounting Type | Through Hole |
| Current - Output | 400mA |
| Operating Temperature | -40°C ~ 125°C |
| Output Configuration | Positive |
| Current - Quiescent (Iq) | 300 µA |
| Voltage - Input (Max) | 26V |
| Number of Regulators | 1 |
| Supplier Device Package | TO-220-5 |
| Voltage - Output (Max) | - |
| Voltage - Output (Min/Fixed) | 4.85V |
| Control Features | Enable |
| PSRR | - |
| Voltage Dropout (Max) | 0.75V @ 400mA |
| Protection Features | Load Dump, Over Current, Reverse Polarity |
| Current - Supply (Max) | 12 mA |
