MIC2846A-PPYMT-TR
IC LED DRIVER LINEAR 20MA 14TMLFManufacturer: Microchip Technology
Categories: LED Drivers
Quality Control: Learn More
The Microchip Technology MIC2846A-PPYMT-TR is a 6-output linear LED driver IC designed for demanding backlight applications. This device offers precise 20mA current control per channel, enabling uniform illumination. Its integrated switches simplify design, and the 14-TMLF® (2.5x2.5) package with an exposed pad facilitates efficient thermal management. Operating from a 3V to 5.5V supply, the MIC2846A-PPYMT-TR is suitable for environments requiring operation between -40°C and 125°C (TJ). This component is commonly found in automotive and industrial display backlighting solutions where accurate current regulation and robust packaging are critical. The component is supplied in tape and reel for automated assembly.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 40 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 14-UFQFN Exposed Pad, 14-TMLF® |
| Voltage - Output | - |
| Mounting Type | Surface Mount |
| Number of Outputs | 6 |
| Frequency | - |
| Type | Linear |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Applications | Backlight |
| Current - Output / Channel | 20mA |
| Internal Switch(s) | Yes |
| Topology | - |
| Supplier Device Package | 14-TMLF® (2.5x2.5) |
| Dimming | - |
| Voltage - Supply (Min) | 3V |
| Voltage - Supply (Max) | 5.5V |
