MIC2846A-MGYMT-TR
IC LED DRIVER LINEAR 20MA 14TMLFManufacturer: Microchip Technology
Categories: LED Drivers
Quality Control: Learn More
The Microchip Technology MIC2846A-MGYMT-TR is a 6-output linear LED driver IC designed for backlight applications. This component features internal switches and offers precise current control with an output capability of 20mA per channel. The device operates within a supply voltage range of 3V to 5.5V and is housed in a compact 14-TMLF® (2.5x2.5) package, suitable for surface mount installation. Its design supports efficient thermal management, operating across an ambient temperature range of -40°C to 125°C (TJ). The MIC2846A-MGYMT-TR is supplied in tape and reel packaging.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 40 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 14-UFQFN Exposed Pad, 14-TMLF® |
| Voltage - Output | - |
| Mounting Type | Surface Mount |
| Number of Outputs | 6 |
| Frequency | - |
| Type | Linear |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Applications | Backlight |
| Current - Output / Channel | 20mA |
| Internal Switch(s) | Yes |
| Topology | - |
| Supplier Device Package | 14-TMLF® (2.5x2.5) |
| Dimming | - |
| Voltage - Supply (Min) | 3V |
| Voltage - Supply (Max) | 5.5V |
Request a Quote
Clients Also Buy
MSL2024-INR
