CL525K4-G
IC LED DRIVER LINEAR 25MA TO252Manufacturer: Microchip Technology
Categories: LED Drivers
Quality Control: Learn More
Microchip Technology CL525K4-G is a linear LED driver IC designed for applications in lighting and signage. This single-output device provides a constant 25mA output current, suitable for driving low-power LEDs. The CL525K4-G supports a wide output voltage range from 1V to 90V and operates from a supply voltage of 4.75V to 90V. Its TO-252 (DPAK) package facilitates surface mounting and efficient thermal management. Operating within a junction temperature range of -40°C to 125°C, this component ensures reliable performance in demanding environments. The device is supplied on tape and reel for automated assembly processes.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 32 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | TO-252-3, DPAK (2 Leads + Tab), SC-63 |
| Voltage - Output | 1V ~ 90V |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Frequency | - |
| Type | Linear |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Applications | Lighting, Signage |
| Current - Output / Channel | 25mA |
| Internal Switch(s) | - |
| Topology | - |
| Supplier Device Package | TO-252 (DPAK) |
| Dimming | - |
| Voltage - Supply (Min) | 4.75V |
| Voltage - Supply (Max) | 90V |
