APTGT600U120D4G
IGBT MODULE 1200V 900A 2500W D4Manufacturer: Microchip Technology
Categories: IGBT Modules
Quality Control: Learn More
Microchip Technology APTGT600U120D4G is a Trench Field Stop Single IGBT Module designed for high-power applications. This component features a 1200V collector-emitter breakdown voltage and a maximum collector current of 900A, with a power dissipation capability of 2500W. The module exhibits a low on-state voltage of 2.1V at 15V gate-emitter voltage and 600A collector current. Input capacitance (Cies) is specified at 40nF at 25V. The APTGT600U120D4G is designed for chassis mounting and operates across a temperature range of -40°C to 150°C (TJ). Its robust construction and performance characteristics make it suitable for use in industrial motor drives, electric vehicle powertrains, and renewable energy systems.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 27 week(s)Product Status: ActivePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | D4 |
| Mounting Type | Chassis Mount |
| Input | Standard |
| Configuration | Single |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Vce(on) (Max) @ Vge, Ic | 2.1V @ 15V, 600A |
| NTC Thermistor | No |
| Supplier Device Package | D4 |
| IGBT Type | Trench Field Stop |
| Current - Collector (Ic) (Max) | 900 A |
| Voltage - Collector Emitter Breakdown (Max) | 1200 V |
| Power - Max | 2500 W |
| Current - Collector Cutoff (Max) | 5 mA |
| Input Capacitance (Cies) @ Vce | 40 nF @ 25 V |
