APTGT50H120T3G
IGBT MODULE 1200V 75A 270W SP3Manufacturer: Microchip Technology
Categories: IGBT Modules
Quality Control: Learn More
Microchip Technology APTGT50H120T3G is a Trench Field Stop IGBT Module featuring a 1200 V collector-emitter breakdown voltage and a maximum collector current of 75 A. This module is configured as a full bridge inverter, delivering 270 W of maximum power. Key electrical characteristics include a Vce(on) of 2.1V at 15V Vge and 50A Ic, with a typically low collector cutoff current of 250 µA. The input capacitance (Cies) is 3.6 nF at 25 V. Designed for chassis mounting, this module integrates an NTC thermistor for thermal management. Operating across a temperature range of -40°C to 150°C, the APTGT50H120T3G finds application in power factor correction and industrial motor drive systems. The component is supplied in Bulk packaging.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 27 week(s)Product Status: ActivePackaging: BulkDownload Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | SP3 |
| Mounting Type | Chassis Mount |
| Input | Standard |
| Configuration | Full Bridge Inverter |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Vce(on) (Max) @ Vge, Ic | 2.1V @ 15V, 50A |
| NTC Thermistor | Yes |
| Supplier Device Package | SP3 |
| IGBT Type | Trench Field Stop |
| Current - Collector (Ic) (Max) | 75 A |
| Voltage - Collector Emitter Breakdown (Max) | 1200 V |
| Power - Max | 270 W |
| Current - Collector Cutoff (Max) | 250 µA |
| Input Capacitance (Cies) @ Vce | 3.6 nF @ 25 V |
