APTGT300A120G
IGBT MODULE 1200V 420A 1380W SP6Manufacturer: Microchip Technology
Categories: IGBT Modules
Quality Control: Learn More
Microchip Technology APTGT300A120G is a Trench Field Stop IGBT module designed for high-power applications. This half-bridge configuration features a 1200V collector-emitter breakdown voltage and a maximum collector current of 420A. With a power dissipation rating of 1380W and a low on-state voltage of 2.1V at 15V gate-emitter voltage and 300A collector current, it offers excellent efficiency. The module's input capacitance is 21nF at 25V. The APTGT300A120G is chassis mounted, utilizing the SP6 package, and operates across a temperature range of -40°C to 150°C. This component is suitable for demanding industries such as industrial motor drives, power supplies, and renewable energy systems.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 27 week(s)Product Status: ActivePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | SP6 |
| Mounting Type | Chassis Mount |
| Input | Standard |
| Configuration | Half Bridge |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Vce(on) (Max) @ Vge, Ic | 2.1V @ 15V, 300A |
| NTC Thermistor | No |
| Supplier Device Package | SP6 |
| IGBT Type | Trench Field Stop |
| Current - Collector (Ic) (Max) | 420 A |
| Voltage - Collector Emitter Breakdown (Max) | 1200 V |
| Power - Max | 1380 W |
| Current - Collector Cutoff (Max) | 500 µA |
| Input Capacitance (Cies) @ Vce | 21 nF @ 25 V |
