APTGT225DU170G
IGBT MODULE 1700V 340A 1250W SP6Manufacturer: Microchip Technology
Categories: IGBT Modules
Quality Control: Learn More
Microchip Technology APTGT225DU170G Trench Field Stop Dual IGBT Module. This component offers a 1700V collector-emitter breakdown voltage and a continuous collector current of 340A. Featuring a Trench Field Stop IGBT type, it is designed for high-power applications with a maximum power dissipation of 1250W. The dual, common source configuration and SP6 package facilitate efficient thermal management and robust system integration, suitable for chassis mounting. Typical on-state voltage is 2.4V at 15V gate-emitter voltage and 225A collector current. Operating temperature range is -40°C to 150°C. This module is utilized in motor drives, renewable energy systems, and industrial power supplies.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 27 week(s)Product Status: ActivePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | SP6 |
| Mounting Type | Chassis Mount |
| Input | Standard |
| Configuration | Dual, Common Source |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Vce(on) (Max) @ Vge, Ic | 2.4V @ 15V, 225A |
| NTC Thermistor | No |
| Supplier Device Package | SP6 |
| IGBT Type | Trench Field Stop |
| Current - Collector (Ic) (Max) | 340 A |
| Voltage - Collector Emitter Breakdown (Max) | 1700 V |
| Power - Max | 1250 W |
| Current - Collector Cutoff (Max) | 500 µA |
| Input Capacitance (Cies) @ Vce | 20 nF @ 25 V |
