APTGT200A170D3G
IGBT MODULE 1700V 400A 1250W D3Manufacturer: Microchip Technology
Categories: IGBT Modules
Quality Control: Learn More
APTGT200A170D3G is a Microchip Technology IGBT module featuring a Trench Field Stop IGBT structure. This half-bridge configuration is rated for 1700V and a continuous collector current of 400A, with a maximum power dissipation of 1250W. The module offers a low collector-emitter saturation voltage (Vce(on)) of 2.4V at 15V gate-emitter voltage and 200A collector current. Input capacitance (Cies) is 17nF at 25V. Designed for robust performance, this component is suitable for high-power applications in industries such as industrial motor drives, renewable energy inverters, and electric vehicle powertrains. It utilizes a D3 package for efficient chassis mounting and operates across a temperature range of -40°C to 150°C (TJ).
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 27 week(s)Product Status: ActivePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | D-3 Module |
| Mounting Type | Chassis Mount |
| Input | Standard |
| Configuration | Half Bridge |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Vce(on) (Max) @ Vge, Ic | 2.4V @ 15V, 200A |
| NTC Thermistor | No |
| Supplier Device Package | D3 |
| IGBT Type | Trench Field Stop |
| Current - Collector (Ic) (Max) | 400 A |
| Voltage - Collector Emitter Breakdown (Max) | 1700 V |
| Power - Max | 1250 W |
| Current - Collector Cutoff (Max) | 5 mA |
| Input Capacitance (Cies) @ Vce | 17 nF @ 25 V |
