APTGT100TA120TPG
IGBT MODULE 1200V 140A 480W SP6PManufacturer: Microchip Technology
Categories: IGBT Modules
Quality Control: Learn More
Microchip Technology presents the APTGT100TA120TPG, a Trench Field Stop IGBT module designed for demanding power applications. This three-phase module features a 1200 V collector-emitter breakdown voltage and a maximum continuous collector current of 140 A, with a power dissipation rating of 480 W. The Vce(on) is specified at 2.1V at 15V gate-emitter voltage and 100A collector current. Input capacitance (Cies) is 7.2 nF at 25 V. The IGBT module is chassis mountable, facilitating efficient thermal management within the SP6-P package. An integrated NTC thermistor provides temperature monitoring capabilities. This component is suitable for use in industrial motor drives, electric vehicle powertrains, and renewable energy systems. The operating junction temperature range is -40°C to 175°C.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 27 week(s)Product Status: ActivePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | Module |
| Mounting Type | Chassis Mount |
| Input | Standard |
| Configuration | Three Phase |
| Operating Temperature | -40°C ~ 175°C (TJ) |
| Vce(on) (Max) @ Vge, Ic | 2.1V @ 15V, 100A |
| NTC Thermistor | Yes |
| Supplier Device Package | SP6-P |
| IGBT Type | Trench Field Stop |
| Current - Collector (Ic) (Max) | 140 A |
| Voltage - Collector Emitter Breakdown (Max) | 1200 V |
| Power - Max | 480 W |
| Current - Collector Cutoff (Max) | 250 µA |
| Input Capacitance (Cies) @ Vce | 7.2 nF @ 25 V |
