APTGLQ600A65T6G
IGBT MODULE 650V 1200A 2000W SP6Manufacturer: Microchip Technology
Categories: IGBT Modules
Quality Control: Learn More
Microchip Technology APTGLQ600A65T6G is a Trench Field Stop IGBT Module featuring a half-bridge configuration. This component offers a 650 V collector-emitter breakdown voltage and a maximum collector current of 1200 A. The module is rated for a maximum power dissipation of 2000 W and has a low collector cutoff current of 600 µA. The Vce(on) is specified at 2.4V at 15V Vge and 600A Ic. Input capacitance (Cies) is 36.6 nF at 25V.
This module includes an integrated NTC thermistor for thermal management and is housed in an SP6 package for through-hole mounting. It operates across a temperature range of -40°C to 175°C (TJ). Applications for this IGBT module include industrial motor drives, power supplies, and electric vehicle charging infrastructure.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 27 week(s)Product Status: ActivePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | SP6 |
| Mounting Type | Through Hole |
| Input | Standard |
| Configuration | Half Bridge |
| Operating Temperature | -40°C ~ 175°C (TJ) |
| Vce(on) (Max) @ Vge, Ic | 2.4V @ 15V, 600A |
| NTC Thermistor | Yes |
| Supplier Device Package | SP6 |
| IGBT Type | Trench Field Stop |
| Current - Collector (Ic) (Max) | 1200 A |
| Voltage - Collector Emitter Breakdown (Max) | 650 V |
| Power - Max | 2000 W |
| Current - Collector Cutoff (Max) | 600 µA |
| Input Capacitance (Cies) @ Vce | 36.6 nF @ 25 V |
