APTGLQ100H65T3G
IGBT MODULE 650V 135A 350W SP3FManufacturer: Microchip Technology
Categories: IGBT Modules
Quality Control: Learn More
Microchip Technology APTGLQ100H65T3G is a Trench Field Stop IGBT Module with a full bridge configuration. This component is rated for a 650 V collector-emitter breakdown voltage and a maximum continuous collector current of 135 A. It offers a maximum power dissipation of 350 W and features a low Vce(on) of 2.3V at 15V gate-emitter voltage and 100A collector current. The module includes an NTC thermistor for integrated temperature monitoring and is designed for chassis mounting. Input capacitance (Cies) is specified at 6.15 nF at 25 V. This IGBT module operates within a temperature range of -40°C to 175°C (TJ). Its robust design makes it suitable for applications in power conversion, industrial motor drives, and renewable energy systems.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 27 week(s)Product Status: ActivePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | Module |
| Mounting Type | Chassis Mount |
| Input | Standard |
| Configuration | Full Bridge |
| Operating Temperature | -40°C ~ 175°C (TJ) |
| Vce(on) (Max) @ Vge, Ic | 2.3V @ 15V, 100A |
| NTC Thermistor | Yes |
| Supplier Device Package | SP3F |
| IGBT Type | Trench Field Stop |
| Current - Collector (Ic) (Max) | 135 A |
| Voltage - Collector Emitter Breakdown (Max) | 650 V |
| Power - Max | 350 W |
| Current - Collector Cutoff (Max) | 50 µA |
| Input Capacitance (Cies) @ Vce | 6.15 nF @ 25 V |
