APTGL60H120T3G
IGBT MODULE 1200V 80A 280W SP3Manufacturer: Microchip Technology
Categories: IGBT Modules
Quality Control: Learn More
Microchip Technology APTGL60H120T3G is a Trench Field Stop IGBT module featuring a full bridge configuration. This chassis mount device offers a 1200V collector-emitter breakdown voltage and a maximum collector current of 80A. With a maximum power dissipation of 280W, it is designed for demanding applications. Key parameters include a Vce(on) of 2.25V at 15V Vge and 50A Ic, and an input capacitance (Cies) of 2.77 nF at 25V. The module operates across a wide temperature range of -40°C to 175°C (TJ) and includes an integrated NTC thermistor for thermal management. The SP3 package facilitates efficient heat dissipation. This component is utilized in sectors such as industrial motor drives, power factor correction, and uninterruptible power supplies.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 27 week(s)Product Status: ActivePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | SP3 |
| Mounting Type | Chassis Mount |
| Input | Standard |
| Configuration | Full Bridge |
| Operating Temperature | -40°C ~ 175°C (TJ) |
| Vce(on) (Max) @ Vge, Ic | 2.25V @ 15V, 50A |
| NTC Thermistor | Yes |
| Supplier Device Package | SP3 |
| IGBT Type | Trench Field Stop |
| Current - Collector (Ic) (Max) | 80 A |
| Voltage - Collector Emitter Breakdown (Max) | 1200 V |
| Power - Max | 280 W |
| Current - Collector Cutoff (Max) | 250 µA |
| Input Capacitance (Cies) @ Vce | 2.77 nF @ 25 V |
