APT70GR120J
IGBT MOD 1200V 112A 543W SOT227Manufacturer: Microchip Technology
Categories: IGBT Modules
Quality Control: Learn More
IGBT Module NPT Single 1200 V 112 A 543 W Chassis Mount SOT-227
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 26 week(s)Product Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | SOT-227-4 |
| Mounting Type | Chassis Mount |
| Input | Standard |
| Configuration | Single |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Vce(on) (Max) @ Vge, Ic | 3.2V @ 15V, 70A |
| NTC Thermistor | No |
| Supplier Device Package | SOT-227 |
| IGBT Type | NPT |
| Current - Collector (Ic) (Max) | 112 A |
| Voltage - Collector Emitter Breakdown (Max) | 1200 V |
| Power - Max | 543 W |
| Current - Collector Cutoff (Max) | 1 mA |
| Input Capacitance (Cies) @ Vce | 7.26 nF @ 25 V |
