APT40GL120JU2
IGBT MOD 1200V 65A 220W SOT227Manufacturer: Microchip Technology
Categories: IGBT Modules
Quality Control: Learn More
Microchip Technology APT40GL120JU2 is a single Trench Field Stop Insulated Gate Bipolar Transistor (IGBT) module. This component features a 1200 V collector-emitter breakdown voltage and a maximum continuous collector current of 65 A. The module dissipates up to 220 W and exhibits a typical Vce(on) of 2.25 V at 15 V gate-emitter voltage and 35 A collector current. Input capacitance (Cies) is specified at 1.95 nF at 25 V. The device is designed for chassis and stud mounting within a SOT-227 package. Operating temperature ranges from -55°C to 175°C (TJ). This IGBT module is utilized in applications such as industrial motor drives and power factor correction.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 27 week(s)Product Status: ActivePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | SOT-227-4, miniBLOC |
| Mounting Type | Chassis, Stud Mount |
| Input | Standard |
| Configuration | Single |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Vce(on) (Max) @ Vge, Ic | 2.25V @ 15V, 35A |
| NTC Thermistor | No |
| Supplier Device Package | SOT-227 |
| IGBT Type | Trench Field Stop |
| Current - Collector (Ic) (Max) | 65 A |
| Voltage - Collector Emitter Breakdown (Max) | 1200 V |
| Power - Max | 220 W |
| Current - Collector Cutoff (Max) | 250 µA |
| Input Capacitance (Cies) @ Vce | 1.95 nF @ 25 V |
