MIC2586-1BM
HOT SWAP POWER CONTROLLERManufacturer: Microchip Technology
Categories: Hot Swap Controllers
Quality Control: Learn More
Microchip Technology's MIC2586-1BM is a single-channel hot swap controller and sequencer designed for general-purpose applications. This device operates over a wide voltage range of 10V to 80V, with a typical supply current of 2 mA. Featuring internal programmability for current limit, fault timeout, slew rate, and undervoltage lockout (UVLO), it offers robust protection and control for power systems. The MIC2586-1BM includes a latched fault feature for reliable system management. It is housed in a 14-SOIC package and suitable for surface mounting. This component is commonly found in industrial, telecommunications, and computing applications where safe insertion and removal of circuit boards from live backplanes are critical.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | Latched Fault |
| Packaging | Bulk |
| Package / Case | 14-SOIC (0.154"", 3.90mm Width) |
| Mounting Type | Surface Mount |
| Type | Hot Swap Controller, Sequencer |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 10V ~ 80V |
| Applications | General Purpose |
| Internal Switch(s) | No |
| Current - Output (Max) | - |
| Supplier Device Package | 14-SOIC |
| Programmable Features | Current Limit, Fault Timeout, Slew Rate, UVLO |
| Number of Channels | 1 |
| Current - Supply | 2 mA |
