TC4427AMJA
IC GATE DRVR LOW-SIDE 8CERDIPManufacturer: Microchip Technology
Categories: Gate Drivers
Quality Control: Learn More
Microchip Technology TC4427AMJA is a dual, independent low-side gate driver IC. This N-channel and P-channel MOSFET driver features non-inverting logic inputs with a 0.8V VIL and 2.4V VIH threshold. The device delivers a peak output current of 1.5A source and 1.5A sink, enabling rapid switching of power MOSFETs. With a supply voltage range of 4.5V to 18V, the TC4427AMJA offers typical rise and fall times of 25ns. Designed for through-hole mounting, it is supplied in an 8-CERDIP package. This component is suitable for applications in automotive, industrial, and power supply control systems requiring efficient gate drive for power switching components. It operates within an ambient temperature range of -55°C to 125°C.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 8-CDIP (0.300"", 7.62mm) |
| Mounting Type | Through Hole |
| Operating Temperature | -55°C ~ 125°C (TA) |
| Voltage - Supply | 4.5V ~ 18V |
| Input Type | Non-Inverting |
| Supplier Device Package | 8-CERDIP |
| Rise / Fall Time (Typ) | 25ns, 25ns |
| Channel Type | Independent |
| Driven Configuration | Low-Side |
| Number of Drivers | 2 |
| Gate Type | N-Channel, P-Channel MOSFET |
| Logic Voltage - VIL, VIH | 0.8V, 2.4V |
| Current - Peak Output (Source, Sink) | 1.5A, 1.5A |
| Programmable | Not Verified |
