MIC4480YM-TR
IC GATE DRVR LOW-SIDE 8SOICManufacturer: Microchip Technology
Categories: Gate Drivers
Quality Control: Learn More
The Microchip Technology MIC4480YM-TR is a dual, low-side gate driver designed for driving N-channel MOSFETs. This inverting and non-inverting driver features independent channels and delivers a peak output current of 2.5A source and 2.5A sink, enabling rapid switching in demanding applications. With a wide supply voltage range of 4.5V to 32V and logic thresholds of 0.8V (VIL) and 2.4V (VIH), it offers robust compatibility with various control systems. The device exhibits typical rise and fall times of 120ns and 45ns, respectively, facilitating efficient power conversion. Packaged in an 8-SOIC format for surface mounting and supplied on tape and reel, the MIC4480YM-TR is suitable for use in industrial automation, power supplies, and automotive systems. Its operating temperature range is -40°C to 125°C.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-SOIC (0.154"", 3.90mm Width) |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Voltage - Supply | 4.5V ~ 32V |
| Input Type | Inverting, Non-Inverting |
| Supplier Device Package | 8-SOIC |
| Rise / Fall Time (Typ) | 120ns, 45ns |
| Channel Type | Independent |
| Driven Configuration | Low-Side |
| Number of Drivers | 2 |
| Gate Type | N-Channel MOSFET |
| Logic Voltage - VIL, VIH | 0.8V, 2.4V |
| Current - Peak Output (Source, Sink) | 2.5A, 2.5A |
| Programmable | Not Verified |
